Name: Bulldozer SHANTUI SD16
SKU: 0

Product Details



Bulldozer SHANTUI SD16

Engine Power：131kW/1850rpm
Overall Unit Weight：17000kg
Engine Model：WP10

Product video

Basic Information

SHANTUI SD16
Parameter Name	SD16	SD16C	SD16E	SD16L	SD16R	SD16D
Performance Parameters
Operating Mass (kg)	17000	17500	17346	18400	18400	18200
Ground Contact Pressure (kPa)	58	50	55	25	25	33.2
Engine
Engine Model	WP10	WP10	WP10	WP10	WP10	WP10
Rated Power/Rated Speed (kW/rpm)	131/1850	131/1850	131/1850	131/1850	131/1850	131/1850
Overall Dimensions
Overall Dimensions (mm)	514034553032	542739003032	534534553032	526241503074	526241503074	526241503074
Driving Performance
Forward Speed (km/h)	F1:0-3.29,F2:0-5.82,F3:0-9.63	F1:0-3.29,F2:0-5.82,F3:0-9.63	F1:0-3.29,F2:0-5.82,F3:0-9.63	F1:0-3.29,F2:0-5.82,F3:0-9.63	F1:0-3.29,F2:0-5.82,F3:0-9.63	F1:0-3.29,F2:0-5.82,F3:0-9.63
Reverse Speed (km/h)	R1:0-4.28,R2:0-7.59,R3:0-12.53	R1:0-4.28,R2:0-7.59,R3:0-12.53	R1:0-4.28,R2:0-7.59,R3:0-12.53	R1:0-4.28,R2:0-7.59,R3:0-12.53	R1:0-4.28,R2:0-7.59,R3:0-12.53	R1:0-4.28,R2:0-7.59,R3:0-12.53
Chassis System
Track Center-to-Center Distance (mm)	1880	1880	1880	2300	2300	2300
Track Shoe Width (mm)	510/560/610	610	560/510/610	1100/950	1100/660	810
Ground Contact Length (mm)	2430	2430	2635	2935	2935	2935
Fuel Tank Capacity
Fuel Tank (L)	315	315	315	315	315	315
Work Equipment
Cutter Type	Angle blade, straight tilt blade, U-blade	Coal pusher blade	Angle blade, straight tilt blade, U-blade	Straight-tilt blade	Sanitation shovel	Straight-tilt blade
Blade Lift Height (mm)
Digging Depth (mm)	540	540	540	485	485	485
Ripper Type	Three-tine cultivator	---	Three-tine cultivator	---	---	---
Soil Loosening Depth (mm)	570	---	570	---	---	---
